Home - Tools - Turning - Threading Cutter Side Cutter - TKFT
TKFT
TKFT
TKFT
TKFT
TKFT
TKFT
TKFT
TKFT

TKFT

Product Selling Points

Interference-Free Machining:
The specialized back-turning design with optimized clearance eliminates collisions with workpieces or fixtures, enabling reliable thread machining on stepped, deep-cavity, or back-facing features on Swiss-type lathes.



High-Rigidity Vertical Mounting:
The vertically installed insert structure greatly enhances rigidity and vibration resistance, perfectly adapting to the high-speed, high-feed cutting conditions of Swiss-type lathes, ensuring consistent thread accuracy and surface finish.



Long-Lasting & Cost-Effective:
Equipped with wear-resistant coatings and optional double-sided cutting edges, the TKFT series delivers extended tool life, reduces tool change downtime, and lowers overall production costs for both ferrous and non-ferrous materials.

Inquiry Now Next Product
Parameters
Product Selling Points
Related Products
Parameters

Machining parameters
Workpiece Material Cutting Speed (Vc) Initial Depth of Cut (1st Pass)
Carbon Steel 70-120 m/min ≤ 0.2 mm
Alloy Steel 70-120 m/min ≤ 0.2 mm
Stainless Steel 60-90 m/min ≤ 0.15 mm
Cast Iron 80 m/min ≤ 0.2 mm
Brass 100-150 m/min ≤ 0.2 mm
Machining pitch corresponding to the model number
Model Metric Pitch (mm) Threads Per Inch (TPI)
TKFT12RN6001 1-2.0 24--12
TKFT12RN5501 — 24-18
TKFT16RN6001 1-2.0 24--12
TKFT16RN5501 — 24-18
TKFT12RA55005 — 48-24
TKFT12RA60005 0.5-1.25 48-24
TKFT12RB60005 0.5-1.25 48-24
Product Selling Points

Interference-Free Machining:
The specialized back-turning design with optimized clearance eliminates collisions with workpieces or fixtures, enabling reliable thread machining on stepped, deep-cavity, or back-facing features on Swiss-type lathes.



High-Rigidity Vertical Mounting:
The vertically installed insert structure greatly enhances rigidity and vibration resistance, perfectly adapting to the high-speed, high-feed cutting conditions of Swiss-type lathes, ensuring consistent thread accuracy and surface finish.



Long-Lasting & Cost-Effective:
Equipped with wear-resistant coatings and optional double-sided cutting edges, the TKFT series delivers extended tool life, reduces tool change downtime, and lowers overall production costs for both ferrous and non-ferrous materials.

FAQ
Q: Who are we?
A:

Our headquarters is located in Zhejiang, China. Starting in 2023, we sold to South Asia (10.00%), Southern Europe (10.00%), Northern Europe (10.00%), Western Europe (10.00%), East Asia (10.00%), Middle East (10.00%), Southeast Asia (10.00%), Eastern Europe (10.00%), South America (10.00%). There are a total number of people in our office.

Q: How do we guarantee quality?
A:

We always provide samples before mass production; We always conduct a final inspection and take photos for customer confirmation before shipment;

Q: What can you buy from us?
A:

Boiling cutters, milling cutters, CNC inserts, grooving inserts, reamers, tool holders, tool sleeves, and other industrial machinery and equipment.

Q: How do we ensure quality?
A:

Our headquarters is located in Zhejiang, China. Starting in 2023, we sold to South Asia (10.00%), Southern Europe (10.00%), Northern Europe (10.00%), Western Europe (10.00%), East Asia (10.00%), Middle East (10.00%), Southeast Asia (10.00%), Eastern Europe (10.00%), South America (10.00%). There are a total number of people in our office.

Q: Why should you buy from us instead of other suppliers?
A:

Wenqiao Sanqiang CNC Tools Co., Ltd., established in 2011, is located in Wenling, Taizhou, China, covering an area of ​​10 mu (approximately 6,667 square meters). We specialize in high-quality CNC cutting tools, including CNC carbide inserts, carbide end mills, and turning tool fixtures. Our quality speaks for itself, resulting in a high customer repurchase rate and numerous positive reviews.

Q: What services can we provide?
A:

Accepted Delivery Terms: -; Accepted Payment Currency: -; Accepted Payment Method: PayPal; Spoken Languages: English, Chinese
